*A beginner-friendly introduction to compilers: follow along as we build a compiler from scratch, or fork the code on GitHub and add your own optimizations too! In this episode: propagating constant values to eliminate more instructions.*

Last time on Compiler Adventures, we wrote an optimization that eliminates no-op instructions like division by one: `div x 1`

. At the end of the post, I challenged you to find other instructions that are always no-ops regardless of the register's value. There are at least two more: "add zero" (e.g. `add x 0`

) and "multiply by one" (e.g. `mul x 1`

) — neither of those examples has any effect on register `x`

regardless of its value.

In this episode, we'll look at how we can use constants to find more no-op instructions that we can eliminate from our program. The starting code for this episode is on GitHub, on branch `part2`

.

Recall that when a MONAD program starts, the values of `w, x, y, z`

are all zero. Let's look at the start of our MONAD input program and simulate by hand what happens to the four registers:

Wow! Other than reading an input number with `inp w`

, pretty much nothing else happens until that `add x 11`

instruction. The `add x z`

and `mod x 26`

instructions have no effect on the registers' values, so we've found more instructions we could optimize out!

In episode 1, our compiler recognized that `div z 1`

is a no-op because it divides by one. Well, why didn't our compiler also notice that the adjacent instructions are no-ops?

It's because they aren't *always* no-ops: `div z 1`

is a no-op *regardless of the value of z*, but

`add x z`

is only a no-op if `z`

is zero. Similarly, the `mul x 0`

and `mod x 26`

instructions here are no-ops only because `x = 0`

before the instruction executes: the operation's result is zero and is written to `x`

, therefore leaving `x = 0`

unchanged.
The no-ops we've looked at so far are all of the "math operation that had the same result as its input register already held" flavor. There are also other ways in which an instruction might have no effect on the rest of the program. For example, an instruction might calculate a value that is never used, and therefore didn't need to be computed in the first place. We'll explore this idea in detail in an upcoming episode.
In order to optimize out instructions like these, we'll need to teach the compiler to track the possible values registers can have.## Tracking register values

A register's value can either be known exactly, or not known exactly. If a register is known to hold number `n`

, let's call that `Exact(n)`

. If the register's value is not known to be any specific number, let's say the register holds `Unknown`

. For our reading and debugging convenience, let's also introduce a third kind of value a register can hold: `Input(i)`

, representing the `i`

th input to the program. (For folks not yet comfortable with Rust, quick reminder that `usize`

is the unsigned integer type Rust prefers for counting things.)

When the program starts, all four registers hold `Exact(0)`

. Then, for each instruction, we evaluate a set of rules to determine what the next register state should be. For example, after reading the first program input with the `inp w`

instruction, the `w`

register's value becomes `Input(0)`

. Otherwise:

- If the instruction operates on two
`Exact`

values, we'll evaluate the operation on those values and record an`Exact`

result. For example,`add x 11`

when`x = Exact(0)`

would produce`Exact(11)`

. - If the instruction is a multiplication and one of the operands is
`Exact(0)`

, the result is`Exact(0)`

regardless of the other operand value. - Otherwise, we aren't able to determine an exact result so we'll record an
`Unknown`

instead. For example,`eql x w`

below is comparing between`Input(0)`

and`Exact(11)`

, and produces an`Unknown`

result. Similarly, the next instruction`eql x 0`

compares`Unknown`

to`Exact(0)`

, and again produces an`Unknown`

result.

Applying these rules, we get the following register values starting from the beginning of the program:

### Aside: Rust syntax primer

We’re about to use some syntax that may feel unfamiliar to folks not yet used to Rust, so let’s explain it first:

`match`

is used for pattern-matching in Rust, in the same way that it is used in Python 3.10+ or in functional languages like Scala. It's a handy concept, and I encourage you to learn about it if you haven't encountered it before!`if let x = y { <code here> }`

is shorthand for:`match y`

, and if the pattern`x`

matches, execute the given code block. The Rust book's chapter on it does a great job of explaining its benefits.

### Implementing the register value rules

Since `inp`

instructions only take one input instead of two, let's make the code handle them separately. For all other instructions, we can handle them with a function that takes an instruction and two `Value`

inputs, and returns the resulting `Value`

.

Observant readers might have noticed this code returns `Unknown`

in
some situations where it could have done better.
*Cue the foreshadowing music.*
We'll improve it further in future episodes.

## Finding more no-op instructions

Earlier, we observed that to detect whether `add x z`

is a no-op, we needed to know if `x`

or `z`

are zero — and now we can! In general, we see that:

`add x y`

is a no-op if`y = Exact(0)`

. However, it is not a no-op if`x = Exact(0)`

since in that case`x`

gets overwritten with`y`

's value.`mul x y`

is a no-op if`x = Exact(0)`

(multiply zero by anything and it stays zero) or`y = Exact(1)`

(multiply anything by one and it doesn’t change). The same no-op rule applies to`div x y`

as well.- For
`mod x y`

, the MONAD language specifies that`x ≥ 0`

and`y > 0`

. Therefore,`mod x y`

is a no-op whenever`x < y`

, since the remainder when dividing a smaller number with a larger one is the smaller number itself. `eql x y`

can be a no-op in two ways. If`x = y`

, we will get the result`x = Exact(1)`

so we have a no-op if`x = y = Exact(1)`

. If`x != y`

then we’ll get the result`x = Exact(0)`

so we have a no-op if`x = Exact(0)`

and`y`

is any`Exact`

value*except*`Exact(0)`

. So`eql x y`

is a no-op if`x = y = Exact(1)`

or if`x = Exact(0)`

and`y != Exact(0)`

.- For the forms of these instructions that involve a literal number instead of a second register, such as
`add x 11`

, we simply consider the literal number as its corresponding`Exact`

value, then apply the same rules as above.

Let’s move forward in two steps. First, let’s write a function that accepts a (non-`inp`

) `Instruction`

and two `Value`

inputs `left`

and `right`

, and returns `true`

if the instruction is a no-op when executed on those values:

For convenience, I've already defined some helper methods on `Instruction`

that simply return the source/destination register index (the `register()`

function) and the literal or register operand, if the instruction has one (the `operand()`

function).

We can now use `is_instruction_no_op`

to find many more no-op instructions than the `remove_div_by_1`

function from the last episode could find. Let's update `remove_div_by_1`

to track registers' values and take advantage of our new functions. It'll still go through the list of instructions, compute how the register values change at each step, and eliminate instructions it discovers are no-ops.
For experienced Rustaceans: this code isn't idiomatic Rust. I'm trying to make it easier to understand for people of any background.

And like that, we've implemented constant propagation! Let's rename `remove_div_by_1`

to `constant_propagation`

to celebrate our achievement!

## Analyzing our optimizations' impact

Let's run our compiler on our Advent of Code input program and measure how well we did:

```
$ cargo run analyze sample_programs/aoc_challenge.txt
Finished dev [unoptimized + debuginfo] target(s) in 0.02s
Running `.../monad_compiler analyze sample_programs/aoc_challenge.txt`
Original vs optimized length: 252 vs 238 (-14)
Optimized is more efficient by: 5.88%
```

Adding constant propagation made our no-op detection twice as good as in part 1! We managed to eliminate 7 more instructions compared to last time, for a total improvement of just under 6%.

On the other hand, maybe constant propagation should have had a larger impact? Let's visualize our optimizations to figure out what's going on.

We’ll use `cargo run registers <monad_program>`

to generate a printout of the register values our optimizations determined at every instruction in the program, together with an indication whether that instruction was detected to be a no-op. I’ll include a few relevant snippets of the input program’s printout here — the full printout is available on GitHub.

The beginning of the program starts looking pretty good: in the first 10 instructions, most register values are `Exact`

, and constant propagation helps eliminate 5 of these 10 instructions as no-ops. That’s a lot better than 6%!

Unfortunately, just a bit farther down, the simulated register values quickly become a sea of `Unknown`

, and few if any no-ops are found:

Compiler optimizations use insight about the program's behavior to make it more efficient. When the program starts, its initial state is fully known: all registers have `Exact(0)`

values, and the only unknowns are values derived from input data read by `inp`

instructions. It's an insight-rich environment and our compiler performs nicely!

Unfortunately, our compiler isn't yet sophisticated enough to continue generating insight about the rest of the program, so its performance drops accordingly. The statistics at the end of the printout summarize the situation: 91.6% of the time, at least one of the values used by the instruction was unknown, and 22.3% of the time, both values were unknown. With so few known values to work with, constant propagation unsurprisingly has a limited effect.

```
Total non-input instructions: 238
- with 1+ non-exact value: 218 (91.6%)
- without any exact values: 53 (22.3%)
```

Shining a light on the patterns hiding within those `Unknown`

values will be the focus of upcoming Compiler Adventures.

## Wrap up + challenge question

Implementing one compiler optimization can open up new opportunities for another optimization to work its magic. We already included part 1's "eliminate no-ops" idea in this episode's constant propagation code. In the next Compiler Adventure, we'll use constant propagation as part of a fascinating new optimization that will become the foundation of most of our future work!

The completed code from this post is on branch `part2_finished`

on GitHub. For a sneak peek of how we can improve our `Unknown`

handling, consider the following program:

```
inp w
add x w
eql w x
```

Right now, our compiler says that last `eql w x`

instruction would evaluate to `Unknown`

:

Look carefully at the register values around `add x w`

and `eql w x`

. Can you figure out what the `eql w x`

evaluates to? Is it really `Unknown`

? Why isn't our current `constant_propagation()`

function able to do better?

All this and more in the next Compiler Adventure — see you next time!
